Centrifugal AC Blower- Single Fan Type: AD180AV

AD180AV

Centrifugal Fans (radial fans) and Industrial Fans Manufacturer-Air Deviser centrifugal fans are with high airflow and pressure, forward curved blades, industrial centrifugal fans mainly apply on machinery such as Heat Shrink Packaging Machine, coffee bean baking machine, bakery machine, printing mchine, UV machine, ovens, convection reflow oven

Characteristics:

1. Single fan type.
2. High revolution speed (1400rpm ~ 1800rpm).
3. Fan's outlet can be mounted with square or circular flange.
4. Direction of fan's outlet is adjustable.
Application:
Can be used for printing machine, kitchen hood, clean room equipment, ventilation system, packing machine, UV dryer etc. for air suction, discharging, ventilation.
Certificate:
United States UL Certification / Europe CUL Certification
Order Information:
Minimum Order: Negotiate
OEM/ODM Product, Branded Product, Buyer's Label Offered
FOB: Taiwan/China Guangdong/China Shanghai/Vietnam
