Air Booster Fan: ADX304CBP

ADX304CBP

Characteristics:
Air booster fan is high air volume blower with compact size for easy installation and maintenance in direct replacement draft inducers. PSC motor mounted with ball bearing is applied for motor shaft to ensure long life operation on the products. Motor is with UL/CUL certified.
Application:
To be attached to the ductwork to increase airflow in HVAC system that can help to evenly distribute air thought out the houses.
Certificate:
United States UL Certification / Europe CUL Certification
Order Information:
Minimum Order: Negotiate
OEM/ODM Product, Branded Product, Buyer's Label Offered
FOB: Taiwan/China Guangdong/China Shanghai/Vietnam
