Centrifugal AC Blower- Single Fan Type: AD077ASP

AD077ASP

Manufacturer of Air Blowers, Centrifugal Blowers, Fan blowers, fan impellers, blower wheels mainly apply on various kind of machines such as boilers, kitchen hood, ovens, packaging machine, baking machine, UV machine, printing for air circulation, air suction and discharging.

Characteristics:

1.Air blower in shaded pole motor .
2. It's compact size is easy for installation and maintenance.
3. Blower motor with UL/CUL approval.
4. Direction of fan's outlet is adjustable.
Application:
Mainly apply on small boiler, machinery, air conditioner, kitchen hood, baking machine, packing machine, UV dryer, air shower etc. Or air suction, discharging, ventilation. furnace blower, heater, oven, HVAC system for air inducting and circulation.
Certificate:
United States UL Certification / Europe CUL Certification
Order Information:
Minimum Order: Negotiate
OEM/ODM Product, Branded Product, Buyer's Label Offered
FOB: Taiwan/China Guangdong/China Shanghai/Vietnam
